Cylinder Heads for CAT, Cummins & Komatsu Diesel Engines

What a Cylinder Head Does and Why Failure is Serious

The cylinder head performs several simultaneous functions inside a running diesel engine. It forms the top seal of the combustion chamber, withstanding combustion pressures of over 2,000 psi on every firing cycle. It houses the intake and exhaust valves and their associated valve guides, valve seats, and springs. It channels engine coolant through internal passages to regulate temperature across the top of the engine block. And it carries the oil galleries that lubricate the valve train and rocker gear above.

When a cylinder head fails, whether through cracking, warping, or internal porosity, these functions break down simultaneously. Coolant enters the combustion chamber, exhaust gases enter the coolant system, and oil contamination follows rapidly. The consequences if the operation continues are severe:

• Hydrostatic lock — coolant flooding the combustion chamber causes catastrophic connecting rod and crankshaft damage
• White exhaust smoke — a visible indicator of coolant combustion that signals active head failure
• Overheating — loss of coolant volume combined with compromised sealing accelerates thermal damage throughout the engine
• Milky oil — coolant contamination of the engine oil destroys bearing surfaces within hours of continued operation

Early diagnosis and replacement are always significantly less expensive than the engine damage that follows from delayed action.

CAT Cylinder Heads: Full Platform Coverage

Caterpillar diesel engines are the most widely rebuilt heavy machinery powerplants in the industry, and Caterpillar cylinder heads are among the highest-demand components in our range. The CAT C15 and particularly the C15 ACERT variant carry a well-documented history of cylinder head failure under sustained high-load operation, making it the single highest-demand platform in our cylinder heads range.

Our CAT cylinder heads range covers:

• CAT C7 — a widely deployed mid-range CAT engine used in excavators, motor graders, and medium plant
• CAT C9 — a reliable platform across a broad range of CAT-powered equipment
• CAT C12 — a high-torque CAT engine with strong demand for replacement cylinder heads
• CAT C13 — deployed across large excavators, haul trucks, and heavy plant applications
• CAT C15 & C15 ACERT — the highest-demand CAT cylinder head in our range, available for both the standard C15 and the ACERT variant
• CAT 3116 & 3126 — reliable multi-application CAT platforms with broad parts support
• CAT 3306 — one of the most widely used CAT engines ever built, with strong ongoing cylinder head demand
• CAT 3406, 3406E & 3406B — the most rebuilt CAT engine family in heavy industry, requiring exact head specification matching for correct compression and torque integrity

All CAT cylinder heads are supplied to OEM dimensional tolerances and pressure-tested before dispatch.

Cummins Cylinder Heads N14, ISX & ISX15 Platforms

Cummins diesel engines are deployed across some of the most demanding heavy equipment and over-the-road applications in the world. Cylinder head failure on Cummins platforms, particularly the N14 and ISX family, is most commonly associated with coolant passage porosity and valve seat recession at high engine hours.

Our Cummins cylinder heads range covers:

• Cummins N14 — a high-torque legacy platform with strong ongoing parts demand across heavy plant and on-highway applications
• Cummins ISX — one of the most widely deployed Cummins engines in modern heavy equipment
• Cummins ISX15 — the high-output variant of the ISX platform, requiring precise head specification for correct combustion geometry
• 12-valve configurations — covering legacy Cummins 5.9 and 6BT platforms used in compact excavators and light plant equipment

All Cummins cylinder heads are surface-checked and pressure-tested before dispatch and cross-referenced to your engine serial number for confirmed fitment.

Signs Your Cylinder Head Needs Replacing

Cylinder head failure rarely presents as a single sudden event. In most cases, warning signs appear progressively, and recognising them early is the difference between a cylinder head replacement and a full engine rebuild.

Key indicators to watch for:

• White or grey exhaust smoke — particularly on cold start or under load, indicating coolant entering the combustion chamber
• Unexplained coolant loss with no visible external leak — coolant is being combusted or passing into the oil system
• Overheating without an obvious cause — compromised head sealing reduces coolant circulation efficiency across the block
• Milky or foamy oil on the dipstick — coolant contamination of the engine oil is a serious and urgent failure signal
• Loss of compression on one or more cylinders — indicates a breach in combustion chamber sealing
• Rough idle and misfiring — particularly on diesel engines- can indicate a cylinder not contributing correctly to power output

If you are seeing any combination of these symptoms, contact Imara Engineering before committing to parts. Our team can help you diagnose whether a cylinder head replacement is the correct first step or whether a more comprehensive overhaul is required.

OEM vs Aftermarket Cylinder Heads: What You Need to Know

One of the most common questions we receive at Imara Engineering is whether an aftermarket cylinder head is a reliable option for a heavy-duty diesel engine rebuild. The answer is straightforward: at the correct specification, an OEM-equivalent aftermarket cylinder head performs identically to an original equipment unit.

The critical factors are dimensional tolerance, material specification, and quality control, not the brand name on the casting. Our cylinder heads are manufactured to the same combustion chamber geometry, valve seat dimensions, head bolt thread specifications, and surface finish standards as the original CAT, Cummins, and Komatsu heads they replace. Every unit is pressure-tested before dispatch. The difference is price, not performance.

For operators working in markets where genuine OEM lead times are extended or costs are prohibitive, OEM-equivalent aftermarket cylinder heads from Imara Engineering are a proven and reliable solution.

Why Source Your Cylinder Heads from Imara Engineering?

Workshop managers and fleet operators across Australia, North America, Canada, and internationally trust Imara Engineering for cylinder heads because we combine technical precision with supply reliability.

• Pressure-Tested Before Dispatch — Every cylinder head is pressure-tested and surface-checked before it leaves our facility. You receive a component that has been verified, not just visually inspected.
• Confirmed Fitment on Every Order — Our team cross-references your machine serial number and engine model before dispatch. The correct head for your specific engine variant — C15 or C15 ACERT, 3406E or 3406B — is confirmed before the order ships.
• OEM-Equivalent Tolerances — Combustion geometry, valve seat dimensions, surface finish, and bolt thread specifications are all manufactured to match the original. Aftermarket quality at Imara means equivalent engineering, not a step down.
• Fast Worldwide Shipping — We dispatch to Australia, the USA, Canada, and internationally. Full tracking on every order, fast turnaround on in-stock units.
• Paired Supply Available — Cylinder head replacement is most effective when paired with a new head gasket kit and valve train components. Our team can consolidate your cylinder head, gasket kit, and ancillary components into a single order.
